96 ports outdoor dome type fiber splice enclosure
|Payment Type:||L/C,T/T,D/P,Paypal,Money Gram,Western Union|
|Terms of Trade:||FOB,CFR,CIF,FCA,CPT,CIP|
|Min. Order:||100 Bag/Bags|
|Delivery Time:||7 Days|
|Place of Origin:||sichuan|
Model No.: HT-96F
Excessive fibers can be stored in storage baskets behind the splice trays.
The optical fibers are taken into from middle of splice tray.
One tray can accommodate up to 24 fiber splices; Per closure can accommodate up to 6 trays.
The dome material mixed chemical agent to resist corrosion and aging and also provide ultra-violet protection.
It can be installed in aerial locations, ducted applications, direct buried, manholes. Small volume but large capacity.
1. Excessive fibers can be stored in storage baskets. Easy in fiber management.
2. Fabricated by mixing the imported material and other chemical assistant agent (ageing resistance & ultraviolet radiation resistance), increase of service life
3. Base-to-dome seals on closure are mechanical and heat-shrinkable for ease of installation and reentry. No other sealing adhesive tape is needed
4. Base and dome sealed with clamp and O-ring system
5. The splice trays are hinged for access to any splice without disturbing others trays
6. The inner parts and fixing parts are made of stainless steel
7. Closure with a earthing device protect it from damage by lightning
8. Compatible with most cable types(single fiber or ribbon), and cable constructions(loose tube, central core, slotted core, modular). And the product can be used in any environment (aerial, buried, handhole, manhole)and in many applications(tap-off, expressed, branch, and repair)
9. No special tools are needed to open the closure, and it can be opened and used repeatedly.
1. Working Temperature: -40 degrees centigrade~+70 degrees centigrade
2. Atmospheric Pressure: 70~150Kpa
3. Axial Tension: >2000N/1min
4. Stretching Resistance: 2500N/10 square centimetre(1min)
5. Insulation resistance: >2*104MΩ
6. Voltage Strength: 15KV/1min, no arcover or breakdown
7. Pressure in the water: 50m/72hours
8. Splice tray with optical taking-in radius≥ 40mm. Low optical loss.
Chengdu HTLL was established in April, 2008, located in the ancient cultural town---Chongzhou, Chengdu. It is a diversified enterprise engaged in communications, networking, sheet metal products manufacturing of electronics industry, CNC machinery equipment manufacturing and selling. And has a high-quality technical and management team with rich experience in R & D and designing sheet metal products, communications equipments. On the basis of business philosophy --[ give full scope to the talents, turn material resources to good account "; market strategy--[price determine market, service cast brand" , enterprise mission --"happy work , to own nice family". HTLL has survived in the rigorous financial crisis environment and achieved great developments luckly , and we will strive to provide the top quality products and the considerate services to all the customers. With the common efforts of all staffs and strong supports of all customers, HTLL has achieved rapid developments since it`s founded: In December 2008, to be a member of short-listed OEM authorization businesses in China Telecom southwestern region. In October 2009, At the forefront of domestic sheet metal manufacturing technology , introduction of international advanced manufacturing equipment--- Germany[TRUMMF" CNC punching and [Amada" bending machine ; In August 2010, Be a Governing unit of Chengdu sheet metal Association; In September 2011, introduction of TRUMMF laser compound machine, in the leading position of domestic laser technology area; In August 2012, moving to the Chong`zhou industrial Park from Qing`yang district, Chengdu. The area covering from 2000 square meters to 8,000 square meters. Up to now, our company has formed a relatively advanced and completed production process, with six sets Germany TRUMMF and AMADA CNC punching, 1 set TRUMMF laser cutting machine, 5 sets CNC bending machine, and several other equipments. Main products: telecommunications, network, electronic industry sheet metal products; electrical and automatic control standard screen cabinets; high-speed railway and subway instruction boards, advertising boards. The manufacturing production is good quality and high technology, strictly accordance with ISO90001: 2008 international quality management system, and has won the majority of the global customers` good praise and support , with high standards, high efficiency, considerate service. Also has set a good business reputation. Based on reality, up to now, our products has exported to south-east of Asia, Europe, south America, and Japan, Korea. look forward to the future, to create a better tomorrow with every customer together!
- Company Name: ChengDu HTLL Electronical Equipment Co.,LTD
- Representative: TongQingwen
- Product/Service: Outdoor Telecommunication Cabinets , Fiber Patch Panels , Network Cabinets , Fiber Optic Distribution Box , FTTH Products , Fiber Optic Heat Shrink Sleeves
- Capital (Million US $): 500000RMB
- Year Established: 2012
- Total Annual Sales Volume (Million US $): Below US$1 Million
- Export Percentage: 31% - 40%
- Total Annual Purchase Volume (Million US $): Below US$1 Million
- No. of Production Lines: 3
- No. of R&D Staff: 5 -10 People
- No. of QC Staff: 5 -10 People
- OEM Services Provided: yes
- Factory Size (Sq.meters): 1,000-3,000 square meters
- Factory Location: No.138 JinJi Road ChongZhou Industrial Park ChengDu China
- Contact Person: Ms. vivi
- Tel: 86-028-82155210
