durable Figure 8 Single Mode strand Fiber Optic Network Cables
Home > Products > Indoor Fiber Optic Cable > durable Figure 8 Single Mode strand Fiber Optic Network Cables

durable Figure 8 Single Mode strand Fiber Optic Network Cables

Product Description

durable Figure 8 Single Mode strand Fiber Optic Network Cables

We are 20 years Fiber Optic Cable manufacturer.
Welcome to go to the factory tour!
Send message to our can get free samples.

Most popular product

durable Figure 8 Single Mode strand Fiber Optic Network Cables





Product Attenuation



2-96 fibers

98-288fibers

Max. Tension (N)

Short-term

1500

3000

Max. Tension (N)

Long-term

600

1000

Max. Crushing Resistance (N/100mm2)

1000

                         Temperature range(°C)

-40°C-- +70°C

Min. Bending Radius(mm)

Install

20D

Min. Bending Radius(mm)

Static

10D



Optical Characteristics



G.652

G.655

50/125μm

62.5/125μm

Attenuation

(+20°C)

@850nm





≤3.0 dB/km

≤3.0 dB/km

@1300nm





≤1.0 dB/km

≤1.0 dB/km

@1310nm

≤0.36 dB/km

≤0.40 dB/km





@1550nm

≤0.22 dB/km

≤0.23dB/km







Bandwidth (Class A)

@850nm





≥500 MHz·km

≥200 MHz·km

@1300nm





≥1000 MHz·km

≥600 MHz·km

Numerical Aperture





0.200±0.015NA

0.275±0.015NA

Cable Cut-off Wavelength λcc

≤1260nm

≤1480nm







Product Description





Fiber pigtails are a great solution for fusion splicing inside of a fiber optic enclosure. The fan-out fiber pigtails come with a partial outer jacket to help protect the tight buffer fibers from being damaged. If space is a premium, the outer jacket can easily be removed, allowing the pigtails to have a tighter bend radius and take up less space.



Features
-Low insertion loss, Low back reflection loss
-Flexible and easy to strip fibre buffering
-Identifiable fibre buffer colours under all lighting conditions
-Reduces installation time
-Avoids incorrect patching by possible fiber flipping



Installation
Indoor Distribution







More Products

Company Information


Exhibition



Certifications



FAQ



FAQ

1. Are you the real factory?

Yes,we are the real factory with 20 years’ history.



2. What is your fiber brand?

Fiber brands including : NECERO,HANXIN,MECABLE



3. What is your main products?

Outdoor fiber optic cables; indoor fiber optic cables;FTTH Drop cables; ADSS;

 Indoor armored patch cords fiber cable; Optical patch cords SC/LC/FC/ST; MTP/MPO optical patch cord.



4. Product quality guarantee period?

25 years’ Guarantee for fiber optic cable



5. Do you have certificate for raw material?

We build long-term relationship cooperation with qualified ISO9001, ROHS  raw material suppliers.



6. What is your delivery time?

Within 24 hours for 30KM normal kinds of fiber optic cable;

 1 ~2 days for fiber optic patch cords with 10000 connectors.



7. MOQ: what is your minimum quantity?

MOQ for fiber optic cables: 1KM

There is no MOQ required for fiber optic patch cords,as there’s stock for normal kinds.



8. Do you have distributor in other country or domestic?

Until now, we sell our products to customers directly. And factory price could be offered.



9. Payment

For large orders: T/T, L/C

For small orders: T/T,Western Union and Paypal are acceptable.



10. Shipping & Delivery

For large orders: by sea (LCL or FCL)

For small orders: by sea (LCL), by air or by courier services,any of which is optional.
